Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Shanghai KUB Refrigeration Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

MOQ : 1

Price : $8,000

Temperature range : -20-8c, 8-18c, 18-20c, 20-25c

Weight : 350 KG

Compressor type : semi-hermetic

Power supply : 380V/3ph /50Hz

Refrigerant : R-404a

Cooling capacity : 5.6-140 kw

Voltage : 1N-220V-50HZ, 3N-380V-50HZ

Noise level : 68-75 dBA

Compressor power : 1.5-9 KW

Gross power : 2.1-43.5 KW

Evaporator type : Copper tube sleeve aluminum fin

Condenser type : Copper tube sleeve aluminum fin

Air output : 400-10000 m³/h

Outlet diameter : 100-200 mm

Electric motor : 0.37-7.5 KW

Contact Now

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Product Description

kub OEM -40degree cold air chiller semi hermetic compressor cold air machine and 2HP to 50HP chiller

Model 2HP 3HP 4HP 5HP 8HP 10HP
Cooling capacity kw 5.6 8.4 11.2 14 22.4 28
Kcal/hr 4816 7226 9632 12040 24080
Voltage 1N-220V-50HZ 3N-380V-50HZ
Margin blast pressure Pa 300 300 300 500 500 500
Noise dBA 68 68 68 72 72 72
Compressor KW 1.5 2.25 3.0 3.75 3.0*2 3.75*2
Gross power KW 2.1 2.9 4.1 5.1 7.9 9.8
refrigerant R22
Evaporator Type Copper tube sleeve aluminum fin
Condenser (hot air) The cooling air volume m³/h 2000 3000 4000
Type Copper tube sleeve aluminum fin
Air blower (cold air) Air output m³/h 400 600 800 1000 1600 2000
The outlet diameter mm 100 100 125 125 150 150
Electric motor KW 0.37 0.37 0.75 0.75 1.1 1.5
Type centrifugal fan
Filter The return air use nylon filter (without air duct)
Temperature of air out 5-20℃(adjustable range, movement deviation +3℃) standard for side air outlet, if the top air outlet and special temperature requirements should be specified
Dimension Length mm 850 1000 1000 1200 1320 1400
Width mm 500 600 600 600 750 780
Height mm 800 880 880 960 1450 1550
Weight kg 80 110 160 180 300 320
Model 12HP 16HP 20HP 30HP 40HP 50HP
Cooling capacity kw 34 42 56 84 112 140
Kcal/hr 28896 36120 48160 72240 96320 120400
Voltage 3N-380V-50HZ
Margin blast pressure Pa 500 500 550 550 600 650
Noise dBA 72 72 75 75 75 75
Compressor KW 4.5*2 5.5*2 7.5*2 7.5*3 7.5*4 9*4
Gross power KW 10.5 11.2 18 26.5 35.5 43.5
refrigerant R22
Evaporator Type Copper tube sleeve aluminum fin
Condenser (hot air) The cooling air volume m³/h 12000 15000 20000 30000 40000 50000
Type Copper tube sleeve aluminum fin
Air blower (cold air) Air output m³/h 2400 3000 4000 6000 8000 10000
The outlet diameter m 180 180 200 200 200 200
Electric motor KW 1.5 2.2 3.0 4 5.5 7.5
Type centrifugal fan
Filter The return air use nylon filter (without air duct)
Temperature of air out 5-20℃(adjustable range, movement deviation +3℃) standard for side air outlet, if the top air outlet and special temperature requirements should be specified
Dimension Length mm 1500 1650 1800 1830 2100 2300
Width mm 850 850 1300 1300 1500 1700
Height mm 1650 1650 1900 1900 1900 1900
Weight kg 380 420 650 700 880 1050

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply
Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Company Information

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power SupplyIndustrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power SupplyIndustrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power SupplyIndustrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

FAQ

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

Q1: Are you a manufacturer or trading company?

A1:This compressor we are agent , But we are factories that produce condensing units, chillers,Evaporator.

Q2: What about the shipping methods?

A2: By express/By air/By sea.

Q3: What about the payment methods &payment terms

A3: We accept T/T ,Paypal, Western Union, Cash and etc.After 30% deposit,and 70%balance before the shipment.

Q4: What's your delivery time?Where is the loading port?

A4: Usually within 35-60 days after receiving the payment. Loading port:Shanghai,other place in china according your requirement.

Q5:Can I have a sample first ?

A5:You have to pay sample cost.

Q6: How do you ship the goods and how long does it take arrive?

A6: We usually ship goods by LCL or FCL by sea, by air or express delivery. Usually it takes 30 days by sea, 5-7 days by air or express delivery.

The delivery time is according to the way of shipping.

Packaging & Shipping

Industrial Water Chiller with -40degree Cold Air Semi Hermetic Compressor 2HP to 50HP and 380V/3ph/50Hz Power Supply

A. Individuation & Customization

Refrigeration industry, cold storage engineering;

Agriculture,food, restaurant, chemical industry; we can undertake designs according to customer's requirements.

B. Excellent warranty

KUB provides up to one year warranty period.

If there is any product quality problems, we will return processing, and is responsible in the end.

We provide excellent service to solve your worries.
